Osculati 4 Position Key Start Ignition Switch with Two Keys
Product code:
709541
Manufacturer SKU:
14.135.00
This 4 position key start switch can be used to activate several accessories.The key slot can be protected by a splash proof flip cover.Each key start switch is supplied with two keys.... Read more
Description
This 4 position key start switch can be used to activate several accessories.
The key slot can be protected by a splash proof flip cover.
Each key start switch is supplied with two keys. Also referred to as an Ignition Switch
- Position 1 - off, key can be removed.
- Position 2 to right - Contact / run. Key cannot be removed.
- Position 3 to right - Start with sprung return to position 2. Key cannot be removed.
- Position 4 - to left of position 1 - Accessories on. Key can be removed. Key must be pushed forward to access this position.
Can be used for petrol or diesel engine applications where wiring permits. Ensure relays are used for heavy current loads.
Hole size required: 22mm diameter, with 2 retaining lugs 3.5mm wide on 19.8mm diameter.
Switch dimensions: 60.5mm long, 44mm diameter, 19.5mm threaded neck length.
| Supplied With | 2 Keys |
| Brand | Osculati |
| Cut Out | 22mm Diameter (with 2 retaining lugs 3.5mm wide on 19.8mm diameter) |
| Length | Switch: 60.5mm long, Threaded Neck: 19.5mm |
| Diameter Description | Switch: 44mm |
