Osculati Lockable Deck Filler Cover Plate (Gas)

Name: Osculati Lockable Deck Filler Cover Plate (Gas)
SKU: 305791

Product code: 305791
Manufacturer SKU: 20.569.01

Description

Stainless Steel 316 lockable deck filler cover plate marked as 'GAS' (Gasoline). The Osculati lockable deck filler cap has a mirror polished finish and fits almost all deck fillers on the market. The deck filler cap can be fitted using the existing securing screws on your deck filler and secured with a padlock (not supplied).

Anti-theft Deck Filler Cover Installation Instructions

1- Remove the mounting screws on the deck filler. Lift the flange about 1/2" from the deck (10 to 15mm).

2- Slide the gasket under the deck fill flange.

3- Slide the mounting bracket between the flange and gasket. The bracket must fit completely into the recess in the gasket.

4- Align the deck fill's mounting holes with slots on the bracket. Secure to the deck with original mounting screws.

5- Use additional screws provided (4) to secure the bracket to the deck.

Attention: To ensure sealing between deck filler and deck, ensure proper contact of gasket and deck. Apply silicone sealant under the flange if necessary.

Specifications

Material	Polished Marine Grade Stainless Steel 316
Primary Construction	Stainless Steel 316
Marking	Gas (Gasoline, Petrol)
Bolt Hole PCD Description	Will suit deck fillers with 3 or 4 holes on a PCD of 61mm to 70mm, Maximum flange diameter: 95mm & Maximum flange height: 17mm
Brand	Osculati
Colour	Silver
