Quick Olympic Plow Anchor (60Kg / Polished Stainless Steel AISI 316)

Quick Olympic Plow Anchor (60Kg / Polished Stainless Steel AISI 316)

Name: Quick Olympic Plow Anchor (60Kg / Polished Stainless Steel AISI 316)
SKU: Q-ANCOLY60S

Product code: Q-ANCOLY60S
Manufacturer SKU: FYANLY060XP0A00

Quick Olympic anchor 60kg in polished stainless steel with a plough-shaped arm.Anchor Specs:• Weight: 60kg (132 lb)• Recommended chain size: 13mm (33/64")• Boat length*:... Read more

Description

Quick Olympic anchor 60kg in polished stainless steel with a plough-shaped arm.

Anchor Specs:

• Weight: 60kg (132 lb)

• Recommended chain size: 13mm (33/64")

• Boat length*: 20 meters (65 ft)

• Boat weight*: 43 tons (47.4 US tons)

• Material: AISI 316 Stainless steel with a polished finish

*NOTE: The indication may vary according to the boat type and the anchor-rode type.

Dimensions (see image for reference):

A: 583mm (22-61/64")

B: 983mm (38-45/64")

C: 23mm (29/32")

D: 25mm (63/64")

E: 797.7mm (31-13/32")

F: 688.4mm (27-7/64")

G: 405.3mm (15-61/64")

H: 340mm (13-25/64")

I: 465.5mm (18-21/64")

The Quick Olympic swivel is available as an optional extra, see part number: Q-OS60S.

Key Features

Detailed engineering & production process

Sheet metal forming, subsequently soldered

Polished AISI 316 Stainless steel

Specifications

Material	Polished Stainless Steel AISI 316
Primary Construction	Stainless Steel 316
Boat Size	Up to 20 meters in length
Brand	Quick
Weight	60kg
Country of Origin	Italy
