Quick Olympic Swivel (8-12mm Chain / 20kg / Satin Stainless Steel)

Quick Olympic Swivel (8-12mm Chain / 20kg / Satin Stainless Steel)

Name: Quick Olympic Swivel (8-12mm Chain / 20kg / Satin Stainless Steel)
SKU: Q-OS20SB

Product code: Q-OS20SB
Manufacturer SKU: FYGAL1020XS0A00

Description

Quick Olympic swivel with satin stainless steel finish, used to safely connect 8-12mm chain to the 16kg or 20kg Olympic anchor during mooring. The chain connector swivel also facilitates raising the chain and anchor through the bow roller, avoiding typical shackle blockage problems. This Quick Olympic swivel, together with the Olympic anchor, features a self-tipping system, which allows the Olympic anchor to always be weighed in the correct position.

Suitable for use with the following chain sizes: DIN/ISO 8mm and 10mm, ISO 12mm, G4/BBB 5/6" and 3/8".

Dimensions:

A: 140mm (5-1/2")

B: 39.5mm (1-35/64")

C: 11mm (27/64")

D: 12mm (15/32")

E: 21mm (13/16")

F: 18.5mm (23/32")

G: 18mm (45/64")

H: 9.6mm (3/8")

Key Features

Self-tipping system

8-12mm Chain

20kg Anchor maximum

Sand blasted stainless steel

Specifications

Material	Satin (Sand Blasted) Stainless Steel
Primary Construction	Stainless Steel
Brand	Quick
Application	Anchors Up To 20kg (44 lb)
Model	OS 10-20
Diameter Description	8mm to 12mm (5/16" to 1/2")
Size	8mm - 12mm Chain
Country of Origin	Italy
